The SWIFT SCAN intraoral scanner is designed to optimize the digital workflow in dental practices, eliminating the need for traditional alginate or silicone impressions.

High-speed scanning at 33 fps in combination with software processing improves scanning and modeling efficiency. High-precision algorithm optimization enables full-arc scanning accuracy of up to 15 μm, ensuring excellent model reproduction and data reliability.

It easily covers areas such as posterior molars and wisdom teeth thanks to its large visible field of 22 mm deep, facilitating the handling of complex intraoral structures.

Lightweight design of only 210 g with ergonomic double button that allows comfortable use and flexible operation.

Built-in UV sterilization activates in standby mode to ensure hygiene and prevent cross-contamination.

Highly stable system, without the need for calibration, reducing operational complexity and maintenance costs.

Includes 4 tips, 2 large and 2 small that adapt to different oral cavities, optimizing comfort and clinical versatility.

Smart Software:

It features AI-powered soft tissue identification technology that allows you to filter unwanted areas such as cheeks and tongue in real-time for a clean and accurate digital model. The AI identifies complex surfaces such as metal crowns, scan bodies, and ceramics, and adjusts scanning algorithms to ensure stability and detail capture.

The scanner software automatically detects intraoral and extraoral scenarios and suggests the optimal scanning mode. It also instantly generates orthodontic treatment simulations to improve patient understanding.

With a single click, it exports the scan data that can be accessed instantly via a QR code, making the clinic more efficient.

*No compatible con sistema operativo Apple (macOS).

DM Nexus Cloud Services Platform:

It enables instant synchronization with labs via the cloud and one-click data sharing for efficient collaboration. Its management dashboard allows you to visualize business information through intuitive graphs and offers a real-time overview of operational performance.

Technical characteristics:

• Full-Arc Scan Accuracy: Up to 15 μm.
• High-speed scanning: 33 fps.
• Visible field: 22 mm depth
• Motion gesture sensor.
• Handpiece: 210 g.
• No calibration required.
• No auxiliary power supply required
• Warranty: 24 months.

Minimum requirements:

• CPU: Intel Core i7-12700H
• Graphics card: NVIDIA RTX3060
• RAM: 32 GB
• Storage: 1 TB SSD
• Operating System: Windows 10/11 64 bit
• Connection: USB 3.0
• Screen resolution: 1920 x 1080 px at 60 Hz.

Supplies include:

1. Handpiece support.
2. Control box.
3. Transformer.
4. 4x Sterilizable scanner tips at 134ºC from 3 to 6 min up to 150 autoclaved:
   1. 2x L tips.
   2. 2x S tips.
5. 2x Control box cables.
6. Cable fixing kit.
